| output function | dark operate |
| emitter / receiver | receiver |
| housing material | brass nickel plated / PC |
| light indicator | LED yellow |
| alignment / soiled lens indicator | flashing light indicator |
| current consumption typ. | 20 mA |
| width / diameter | 18 mm |
| actual range Sb | 16 m |
| height / length | 67 mm |
| operating temperature | -25 … +55 °C |
| response time / release time | |
| sensitivity adjustment | potentiometer, 270° |
| protection class | IP 67 |
| voltage supply range +Vs | 10 … 30 VDC |
| short circuit protection | yes |
| current consumption max. (no load) | 20 mA |
| output circuit | PNP |
| type | cylindrical threaded |
| manufacter SKU | FEAM 18P3150/S14 |
| voltage drop Vd | |
| type | through beam sensor |
| reverse polarity protection | yes |
| output current | |
| front (optics) | PC |
| nominal range Sn | 20 m |
| connection types | connector M12 4 pin |
Buy Baumer FEAM 18P3150/S14 with the best possible price and delivery terms on eltra-trade.com
