| Baumer Article no | 11217578 |
| Measuring range | 0 … 500 N |
| Non-linearity | |
| Repeatability | |
| Temperature effect zero | |
| Zero point deviation | |
| Type | Button |
| Mechanical mounting | 4 x M2 screws / loose |
| Dimensions | x 19 mm x 11 mm |
| Overload | 150 % |
| Breaking load | 200 % |
| Fatigue strength | >10 Mio cycles at 0…100% FS |
| Nominal displacement | 13 Ојm |
| Weight | 14 g |
| Material sensor body | Stainless steel, 1.4542 |
| Electrical connection | M5, 4 pin, male |
| Nominal sensitivity | 1 mV/V |
| Bridge resistance | 1000 О© |
| Supply voltage | 0.5 … 12 VDC |
| Signal polarity positive | Compression |
| Operating temperature range | -40 … 85 В°C |
| Storage temperature range | -40 … 85 В°C |
| Protection class EN 60529, ISO20653 | IP 67 |
| UL listed | E217824 |
Buy Baumer DLM20-BU.501.CP3.M4 with the best possible price and delivery terms on eltra-trade.com
