Analog I/O module Q.bloxx XL A1168 analog inputs, bridge configurable.

8 analog input channels for strain gages full-, half-, and quarter-bridge configuration, configurable per channel Selectable input ranges for optimal signal-to-noise ratio 2.5 or 10 mV/V for half- and full-bridge, 1 or 10 mV/V for quarter-bridge High-accuracy digitization 24-bit ADC, 20 kHz sample rate per channel Active lead wire resistance compensation online compensation signal (OCS) for continuous compensation of lead wire resistance changes Shunt calibration per channel Galvanic Isolation channel to supply to interface

Технические характеристики

CharacteristicsSignal typeanalogNumber of inputs/outputs8 analog inputsMountingbridgeOther characteristicsconfigurable
