Please Note you can specify and order your pressure gauge in our webshop https://store.ametekstc.com/pressure-measurement/pressure-gauges/general-purpose-gauges/ U.S. Gauge P-570 utility gauges provide economical, reliable service in a wide range of applications includ-ing pumps, compressors, and other equipment. Series P-570 utility gauges come in ranges of: 0-30 through 0-300 psi, with accuracy of ±3-2-3% of span. Gauges are available in 2′ polypropylene cases with 1/8-27 or 1/4-18 NPT center-back or lower mount connections. BOURDON TUBE: Phosphor bronze WINDOW: Polycarbonate MOVEMENT: Brass DIAL: Galvalume POINTER: Aluminum CASE: Polypropylene CONNECTION: 1/8-27 NPT, 1/4-18 NPT, center-back or lower mount
Технические характеристики
CharacteristicsPressure typeabsoluteDisplayanalogMountingthreadedMaterialbrass, aluminumTechnologyBourdon tubeApplicationsprocessOther characteristicsOEM, economicalPressure
Min.: 0 psi
Max.: 300 psi
Precision
2 %, 3 %
Dial diameter
2 in
