9698888- Turbo-V 3K-G Turbo Pump and Controller, DN 250 ISO-F, integrated purge & vent device. Pumping Systems include Pump and Controller with 230 V Integrated Electronics, inlet screen installed on the pump, separate centering ring and pre-installed IP54 mating connectors.

Технические характеристики

Ambient Operating Temperature	+5 to +35 °C
Ambient Storage Temperature	-20 to +70 °C
Base Pressure	-8 mbar <!— Base Pressure::
Compression Ratio He	6 x 103
Compression Ratio N2	>1 x 107 1 x 107 —>
Flange Type	ISO 250 F
Foreline Flange Size	KF 40 NW
Pumping Speed — Ar	2050 L/s
Pumping Speed — He	1900 L/s
Pumping Speed — N2	2200 L/s
Standards and Certifications	EN 55011 (Radio disturbance characteristics) EN 61000-3-2 (Limits for harmonic current emissions) EN 61000-3-3 (Limitation of voltage changes, voltage fluctuations and flicker) EN 61000-6-2 and EN 61326 (Immunity for industrial environments) which recall: EN 61000-4-2 (Electrostatic discharge phenomena) EN 61000-4-3 (Radiated high-frequency phenomena) EN 61000-4-4, EN 61000-4-5, EN61000-4-6 (Conducted high frequency phenomena) EN 61000-4-11 (Voltage fluctuation, voltage dips and short interruptions) <!— Standards and Certifications::EN 55011 (Radio disturbance characteristics) EN 61000-3-2 (Limits for harmonic current emissions) EN 61000-3-3 (Limitation of voltage changes, voltage fluctuations and flicker) EN 61000-6-2 and EN 61326 (Immunity for industrial environments) which recall: EN 61000-4-2 (Electrostatic discharge phenomena) EN 61000-4-3 (Radiated high-frequency phenomena) EN 61000-4-4, EN 61000-4-5, EN61000-4-6 (Conducted high frequency phenomena) EN 61000-4-11 (Voltage fluctuation, voltage dips and short interruptions) —>
UNSPSC Code	40151502
Weight	52 kg
