Additional Features:
- Measures resistances up to 1016Ω
- 1fA-20mA current measurement range
- <,20μV burden voltage on lowest current ranges
- 200TΩ input impedance
- <,3fA bias current
- Up to 425 rdgs/s
- 0.75fA p-p noise
- Built-in ±1kV voltage source
- Unique voltage reversal method for high resistance measurements
Accessories Supplied:
- 237-ALG-2 Low Noise Triax Cable, 3-slot Triax to Alligator Clips, 2m (6.6 ft)
- 8607 Safety High Voltage Dual Test Leads
- 6517-TP Thermocouple Bead Probe
- CS-1305 Interlock Connector
Applications:
- Polymer electrical characterization
- Beam measurements
- Dosimetry
- Device leakage current measurements
- Insulation resistance measurements
- Optoelectronic detector characterization
- Volume and surface resistivity
- Nanomaterial characterization
Keithley’s 5½ digit 6517B Electrometer/High Resistance Meter offers accuracy and sensitivity specifications unmatched by any other meter of this type. It also offers a variety of features that simplify measuring high resistances and the resistivity of insulating materials. With reading rates of up to 425 readings/second, the Keithley 6517B is also significantly faster than competitive electrometers, so it offers a quick, easy way to measure low-level currents.
Технические характеристики
| Manufacturer | Keithley |
|---|---|
| Condition | New |
