Features:
- Type: CW-807
- Alloy: SAC305
- Diameter: .32″
- Package: 1 lb. Spool
- Halogen-free
- Clear residue
- Compatible with Pb-free and SnPb alloys
Physical Properties:
- IPC J-STD-004 Classification: ROL0
- IPC J-STD-004B Classification: ROL0
CW-807 is Indium Corporation»s best-selling flux-cored wire, primarily because it is compatible with all Indium Corporation no-clean solder pastes, wave fluxes, and all common soft solder alloys. It also solders very well while still meeting the most recent requirements of J-STD-004B type ROL0. CW-807 contains less than 500ppm total halogen, so it can be considered halogen-free by both J-STD-004B and JEITA ET-7304. CW-807 passes the more stringent Surface Insulation Resistance (SIR) and Electromigration (ECM) requirements of J-STD-004 revision B, therefore, the no-clean residue will be electronically safe for virtually all applications. Also when properly configured*, cored wire with CW-807 yields superior results in automated soldering operations, including laser soldering.
Технические характеристики
| Manufacturer | Indium |
|---|---|
| Condition | New |
| TYPE | CW-807 |
| PACKAGE | 1 lb. Spool |
| DIAMETER | .032′ |
| ALLOY | SAC305 |
