• Hardened and polished guideways • Safety Guard for Lathe Chuck with micro switch • Emergency Stop Button • Siemens Electrical System • Lathe Foot Brake • Protective Chuck and Tool Holder Shields • Coolant System • CE Standard Standard Accessories • 3 jaw lathe chuck – Ø200 mm • 4 jaw lathe chuck – Ø200 mm • Face plate – Ø250 mm • Steady Rest • Follow Rest • MT3 live center • MT3 dead center • MK5/MT3 Reduction Sleeves • Thread Gauge • Quadruple tool holder • Halogen machine lamp • Replaceable Gear Set • Operating Tools
Технические характеристики
CharacteristicsControl typeconventionalSpindle orientationhorizontalNumber of axes2-axisDiameter
320 mm, 430 mm (12.6 in)
Spindle speed
Max.: 1,800 rpm (11,309.734 rad.min-1)
Min.: 65 rpm (408.407 rad.min-1)
Bar capacity
38 mm (1 in)
Nominal power
1.5 kW (2 hp)
Overall lenght
1,985 mm (78 in)
Overall width
750 mm (30 in)
Overall height
1,320 mm (52 in)
Weight
410 kg (904 lb)
