Additional Features:
- Test Parameters: L/C/R/Z/Y/DCR/Q/D/ θ
- Test Frequencies: 1 kHz ~ 10 MHz
- Test Level: 10mV ~ 5V
- Basic Accuracy: 0.1%
- 15ms fast speed measurement
- 3 kinds of output impedance modes
- Test signal monitoring function
- Compare & bin-sorting function
- Open/short zeroing & load correction functions
- Detached measurement & display unit design
- Standard Handler, RS-232C, USB storage & external bias current control interface
- Optional GPIB or LAN interfaces
The Chroma 11050 HF LCR Meter is a precision test instrument for measuring and evaluating passive components with high accuracy and speed. Measurements include the primary and secondary parameters required for testing inductance, capacitance, resistance, quality factor, and loss factor of passive components. The HF LCR Meter has broad testing frequency ranges from 1 kHz to 10 MHz that are suitable for analyzing passive component characteristics under different frequencies. With 0.1% basic measurement accuracy the 11050 HF LCR Meter makes for measured results that show high stability and also high reliability. The fast 15ms measurement speed effectively increases productivity when working with automated machines.
Технические характеристики
| Manufacturer | Chroma |
|---|---|
| Condition | New |
| Frequency | 10 MHz |
