ZM-5 High Speed Rotating Scanner

The Zetec ZM-5 High Speed Rotating Scanner is a convenient handheld tool designed for rapid and thorough inspection of small diameter holes, such as bolthole and fastener holes. With its ergonomic design, the ZM-5 enables the inspection of hard to reach areas with ease. A state-of-the-art rotating transformer couples the eddy current signals for an improved operating life over conventional slip rings.

Доставка импортных компонентов по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.

Оплата физическими и юридическими лицами безналичным расчетом.

Цена может измениться после запроса у поставщика!

Product Information Specifications

Rotation Speed 600 to 3000 rpm
Frequency Range 50 kHz to 6 MHz
Weight 145 g (5.1 oz)
Size (L x W x H) 81 x 23 x 36 mm (3.2 x 0.9 x 1.4 in)

Supported Instruments and Components

Zetec MIZ-21C using the 6-ft ZM-5 High Speed Rotating Scanner Control Cable (111A810-00)
Cable Connector 18-pin Lemo
Rotating Scanner Probes with 4-pin Fischer connector from Zetec or other manufacturers

Ordering Info 169A901-00 (ZM-5 includes a sturdy, lightweight carrying case, control cable, and USB flash drive with user manual)

ZM-5 High Speed Rotating Scanner

Технические характеристики
