The 632811-117 Fiber Laser Protective Window is made of fused silica material and is Trumpf® OEM compatible. It has a diameter of 0.94 in. (24 mm), edge thickness of 5.0 mm. These fused silica parallel optical windows feature a high 20J/cm2 laser induced damage threshold (LIDT), and a low 10-50 ppm absorption.
Технические характеристики
- Diameter 24.0 mm
- Material Fused Silica
- Antireflection Coating 1030 to 1090 nm
- Reflectance
- Transmittance >99.6% @ 1030 nm
>99.9% @ 1064 nm
>99.6% @ 1070-1080 nm - Thickness 5.0 mm
- Thermal Expansion Coefficient ∆n/∆T 9.6×10-6 K-1
- Damage Threshold 20J/cm2
- Absorption 10-50 ppm
- OEM Compatibility Trumpf®
