| 230V ±10%, 47-63 Hz |
| Internal IEEE-488 Interface |
Features:
- Voltage: 0-7V
- Current: 0-6A
- Power: 42W
- Modular Design
- 115 VAC, 60 Hz single phase input standard
- Simultaneous digital displays of voltage and current on large, easy to read LEDs
- Unique twin LED analog bar graphs show relative voltage and current levels
- Automatic crossover into voltage or current mode with overvoltage/overcurrent signal LED
- No overshoot at turn-on, turn-off or power failure
- Series or Parallel Operation
- Regulation: 0.02% line and load + 4 mV regulation
- 100 μs transient response with ±50% load change (typical)
- Ripple: 1.0 mV RMS ripple
- High resolution 10-turn potentiometer provides precise output voltage control
- CE Mark
The Xantrex XTS7-6, 7V, 6A, 42W, programmable power supplies are designed for benchtop and portable applications requiring affordable, low noise and low ripple performance. Single output models may be configured into a standard package providing dual, triple or quad outputs for a custom configuration. Customer-installed rack adapters are available for all rackmount configurations.
Технические характеристики
| Manufacturer | Xantrex |
|---|---|
| Condition | Used |
| Current | 6 A |
| Voltage | 7 V |
| Power | 42 W |
