X-ray TDI camera C10650-261V

X-ray TDI camera C10650-261V is useful for in-line applications requiring high-speed operation with high sensitivity. TDI imaging is appropriate for applications where it is desired to record a linear movement, or where the aspect ratio of the subject being imaged is significantly asymmetric. Low brightness under high resolution usage, a problem with conventional line sensor cameras, is improved with this X-ray TDI camera, making it suitable for applications which require high resolution. Vertical X-ray TDI cameras that can be installed in narrow spaces are new additions to the series.

Доставка импортных компонентов по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.

Оплата физическими и юридическими лицами безналичным расчетом.

Цена может измениться после запроса у поставщика!

Технические характеристики

Type number	C10650-261V
Scintillator	FOS (Fiber optic plate with scintillator)
Effective X-ray tube voltage range	Approx. 25 kV to 90 kV*1
Number of pixels	3072 (H) × 128 (V)*2
X-ray sensitive area	146.9 mm (H) × 6.1 mm (V)*2
Line speed	0.178 m/min to 6.073 m/min
TDI line rate	1×1: Max. 2.109 kHz (6.073 m/min) Binning 2×2: Max. 1.858 kHz (10.702 m/min)
A/D converter	16 bit
External control interface	Camera Link Base Configuration
Pixel clock	16.0 MHz (Camera Link)
Power supply	DC +15 V
Power consumption	Approx. 20 VA
