Features — Extremely high power rating — up to 50% more than standard Belts — High efficiency up to 98% — Special cord for maintenance-free operation — Extended service life & less machine down-time — Anti-static complies with ISO 1813 — Superior oil & heat resistance — REACH & RoHS compliant provides an eco-friendly system — Extended temperature range -25°C to +100°C Constructional Details 1.High wear-resistant outer jacketing, offers higher gripping strength 2.Maintenance-free, low-stretch, premium polyester cords prevent elongation in the Belt 3.Fibre-filled base compound for increased transverse rigidity Applications Hot rolling mills, power plants, heat exchanger, compressors, vacuum pumps, grinders, kilns, blenders, excavators, paper & pulp industry, etc.
Технические характеристики
CharacteristicsTypeendless, VMaterialrubberProduct applicationsfor heavy-duty applications, for machine tools, for machines, agricultural, for automobilesSectorindustrialOther characteristicswrapped, for heavy loads, maintenance-free, anti-static, high-performance, high-power, oil-resistant, heat-resistantLength
Max.: 23,629 mm (930.28 in)
Min.: 479 mm (18.86 in)
Width
Max.: 25.4 mm (1 in)
Min.: 9.7 mm (0.38 in)
Thickness
Max.: 23 mm (0.91 in)
Min.: 8 mm (0.31 in)
