Discharge rubber hose suitable for the delivery of abrasive material mixed with water. Especially used in the dredging system as connection between pump and suction pipe, discharging the material collected from the dredger. It can be manufactured in service lenghts with enlargerd cuffs, vulcanised flanges, vulcanised flanges rubber protected or beaded ends.
Технические характеристики
CharacteristicsUsefor water, for powdersMaterialnatural rubber, SBRApplicationsdischarge, for pumpsOther characteristicsabrasion-resistant, for abrasive products, braidedInner diameter
Min.: 102 mm (4.016 in)
Max.: 508 mm (20 in)
Outer diameter
Min.: 139 mm (5.472 in)
Max.: 550 mm (21.654 in)
Pressure
8 bar (116.03 psi)
Temperature
Min.: -40 °C (-40 °F)
Max.: 70 °C (158 °F)
Delivered length
12 m (3904)
