Product advantages: ◾generously dimensioned dialogue areas inclined by 72° and 18° for face to face electronic devices, for example, user inputs data on the top and another person reads the displays/printouts on the front face ◾highly attractive contoured design suitable for desktop and wall mounted applications ◾two sizes, each with twelve versions ◾recessed areas 0.6 mm (labels) or 1.4 mm (membrane keypads) deep on the front part and on top part ◾uniquely, it is possible to have an all over product label ◾versions with battery compartment for 3 or 5 x AA cells ◾flexible component mounting, PCBs can be positioned in the bottom, top and front parts, screw pillars integrated ◾electronics and interfaces can be installed as complete packages, top and front part are at right angles to each other ◾protection class IP 40 ◾hidden wall mounting in different orientations, separate wall suspension element (accessory)
Технические характеристики
CharacteristicsConstructionwallMaterialplasticProtection levelIP40Width
Max.: 148 mm (5.8 in)
Min.: 125 mm (4.9 in)
Height
Max.: 80 mm (3.1 in)
Min.: 69 mm (2.7 in)
Depth
Max.: 210 mm (8.3 in)
Min.: 177 mm (7 in)
