This standalone data logger measures and stores more than 32,000 temperature readings from its high accuracy thermocouple temperature probe. It is designed to monitor vaccines in cryogenic dry ice storage.
The user can easily set up the logger and view downloaded data by plugging the data logger into a PC»s USB port and using the free EasyLog software. Data can then be graphed, printed and exported to other applications for detailed analysis.
Features:
- Measurement range -100 to +100°C
- High accuracy T-Type probe on 2m cable
- Stores over 32,000 readings
- Logging rates between 1 second and 12 hours
- Immediate, delayed and push-to-start logging
- User-programmable alarm thresholds
- Status indication via red and green LEDs
- EasyLog software available as a free download
- Included: lithium metal battery (typically 2 years» life), T-type thermocouple probe, mounting bracket
Specifications:
Model EEL-USB-ULT+
(high accuracy) EEL-USB-ULT
(standard) Temperature Range
-100°C to 100°C
Resolution
0.5°C
Accuracy ±1.8°C typical
±2.5°C typical
Logging Rate
User selectable between 1 second & 12 hours
Operating Temperature Range
-10 to +40°C (data logger only)
Battery Life
2 years (at 25°C and 1 minute logging rate)
Readings
32,510
Dimensions 135 x 24 x 21mm
Probe Dimensions 300 x Φ 1.5mm, 2m cable
Accessories BAT 3V6 1/2AA replacement battery, Replacement T-type thermocouple probe, Handheld datalogger programmer & collector
