The Mitutoyo ratchet stop outside micrometer is ideal for measuring metal and non-metal workpieces by controlling the amount of force applied by the spindle. A ratchet-stop mechanism provides uniform pressure on a workpiece for precise, repeatable measurements. Interchangeable anvils allow for measuring a wide range of workpiece sizes.
- Available in inch and inch/metric models
- Ratchet mechanism provides an audible click to ensure measurement is being performed at a constant pre-set force
- Functions include Origin Set, Zero/ABS, Hold, Function Lock, Data Output, and inch/mm conversion (on inch/metric models only)
- Alarm: Low Voltage, Counting Value Composition Error
- Zero-setting standards bar for each range is included
- Scale is laser etched on thimble for quick and easy reading
- Carbide facing on the spindle resists wear to keep surfaces flatter with longer accuracy
- Speeder is always available for quick rotation of the spindle
- Supplied in a fitted wooden case
| Order No.: | Product Image: | Range: | Accuracy: | Graduation: | Mass: | Flatness: | Parallelism: | |
|---|
| 104-137 |  | 0-6″ | ±0.0003″ | 0.00100″ | 1.35kg | — | 0.00016″ or less |
| 104-138 | — | 6-12″ | ±0.0004″ | 0.00100″ | 2.65kg | — | 0.00020″ or less |
| 104-152 | — | 12-16″ | ±0.00015″ | 0.00100″ | 3.31kg | — | 0.00024″ or less |
| 104-153 | — | 16-20″ | ±0.00015″ | 0.00100″ | 4.81kg | — | 0.00028″ or less |
| 104-154 | — | 20-24″ | ±0.00015″ | 0.00100″ | 6.35kg | — | 0.00032″ or less |
| 104-155 | — | 24-28″ | ±0.00015″ | 0.00100″ | 7.72kg | — | 0.00036″ or less |
| 104-156 | — | 28-32″ | ±0.00015″ | 0.00100″ | 9.08kg | — | 0.00040″ or less |
| 104-157 | — | 32-36″ | ±0.00015″ | 0.00100″ | 10.41kg | — | 0.00044″ or less |
| 104-158 | — | 36-40″ | ±0.00015″ | 0.00100″ | 11.78kg | — | 0.00048″ or less |
| 104-165 | — | 0-2″ | ±0.0001″ | 0.00010″ | 0.32kg | — | 0.00008″ or less |
| 104-201 | — | 12-18″ | ±0.00015″ | 0.00100″ | 4.69kg | — | 0.00026″ or less |
| 104-202 | — | 18-24″ | ±0.00015″ | 0.00100″ | 6.51kg | — | 0.00032″ or less |
| 104-203 | — | 24-30″ | ±0.00015″ | 0.00100″ | 9.95kg | — | 0.00038″ or less |
| 104-204 | — | 30-36″ | ±0.00015″ | 0.00100″ | 11.87kg | — | 0.00044″ or less |
| 104-205 | — | 36-42″ | ±0.00015″ | 0.00100″ | 13.68kg | — | 0.00050″ or less |
| 104-137 |
| 104-138 |
| 104-152 |
| 104-153 |
| 104-154 |
| 104-155 |
| 104-156 |
| 104-157 |
| 104-158 |
| 104-165 |
| 104-201 |
| 104-202 |
| 104-203 |
| 104-204 |
| 104-205 |
Технические характеристики
| Technology: | Mechanical |
|---|
| Units: | Inch |
|---|
| SPC Output: | No |
|---|
| Ratchet/Thimble: | Ratchet Stop |
|---|
| Measuring Force: | 5-10N |
|---|
| Measuring Faces: | Carbide tipped (spindle only) |
|---|
