Description
The viZaar VUMAN E3 and E3+ are the ultimate videoscopes for long-range, remote visual inspections. More than any other long-range video endoscope, the VUMAN® E3/E3+ has unique features that enable a wide variety of inspections, including:
- Interchangeable probes up to 30 meters in probe length
- Probes in different diameters (6mm / 8mm / 12mm)
- X-WAY pneumatic 4-way camera articulation
- Detailed remote focus from 3 mm to ∞
VUSCREEN — Offering Enhanced Visibility
The VUSCREEN control unit of the VUMAN® E3 video endoscope is both ergonomic and powerful. The VUSCREEN attaches directly to the VUMAN® for easy portability and positioning — it fits on top or the back of the unit, and you can carry it with a shoulder strap or simply put it down on a workbench or ground. Minimizing fatigue from lengthy inspections is easy thanks to the resistive, true color, 10.4” touchscreen TFT display with its LED backlight and native resolution of 1024 x 768 px.
Full 4-Way Articulation
The pneumatic X-WAY probe features full 4-way articulation (up/down/left/right) and uses a joystick articulate the direction and degree of the probe. There is no need for external compressed air sources for powering articulation as the probe is driven by a computer-controlled micro compressor.
Interchangeable Probes, Improved Efficiency & Cost Savings
The interchangeable design of the VUMAN makes swapping in the right probe to meet your inspection needs simple and easy. A wide range of short and long range video probes which can be changed on site or in the field, increases inspection efficiency and minimizes downtime. Interchangeable probes enables you to purchase a single system, increasing cost-savings and lowering the cost of repairs. In addition, if a probe should become contaminated, you can simply detach the probe and replace it with a new one, instead of replacing the entire video endoscope system.
Different Probes for Different Applications
With a number of probe options, including different lengths, diameters, articulating or non-articulating, the VUMAN gives you optimal inspection dexterity. There are articulating video probes up to 30 m length and the the VUMAN® E3/E3+ works well for applications requiring a long endoscope range. Optical adapters that allow different direction of view (DOV) and field of view (FOV) can be added to any system. External video endoscopes such as the VISIO system can be connected to the VUMAN®.
The viZaar VUMAN E3/E3+ is ideal for the following industries:
- Nuclear industry
- Pharmaceutical industry
- Construction
- Offshore
- Landfill and gas collection
- Security
- Power generation
- Marine / naval
Технические характеристики
Specs
| Vuman E3 | Vuman E3 X-Way | Vuman E3+ | Vuman E3+ X-Way | |
| X-Way Drive | — | Integrated compressor, maintenance free | — | Integrated compressor, maintenance free |
| System memory | 10GB SSD | 10GB SSD | 80GB SSD | 80GB SSD |
| Video input | — | — | PAL/NTSC, Composite, S-Video | PAL/NTSC, Composite, S-Video |
| Video output | HDMI | HDMI | HDMI, optionally with additional TV-Out (Composite, S-Video) | HDMI, optionally with additional TV-Out (Composite, S-Video)* |
| Weight | 8.2 kg/18.1 lbs | 10 kg / 22 lbs | 8.2 kg/18.1 lbs | 10 kg / 22 lbs |
| Probe Length | max. 20 m/65.6 ft | max. 20 m/65.6 ft or 30 m*/100 ft | ||
| Dimensions (WxHxD) | 340mm x 420mm x 280mm 13.39 x 16.54 x 11.02 | |||
| LED light source | Color temperature: 5.800 K, lifetime warranty | |||
| VUSCREEN mount | ✓ | |||
| VUSCREEN transport bracket | ✓ | |||
| Connectors | USB 3.0, 12V (DC)/750mA Out, optional external compressed air (X-WAY) | |||
| AC Input | 100V (AC) — 240V (AC), 50 Hz — 60 Hz, max. 240 Watt | |||
| Construction | Aluminium-Carbon fiber with elastomer bumpers | |||
| Environmental | Operation: -10C (+14F) to +48C (+118F) Storage: -25C (-13F) to +65C (+149F) Relative humidity: max. 95 %, non-condensing |
* The 30m version of VUMAN® E3+ X-WAY is always fully equipped and comes with an extended probe deployment drum.
