Visual Testing Kit (VT Kit)

The Flawtech Visual Kit Contains: 7 plates & 3 Tees. Each specimen contains 2 “REAL FLAWS,” randomly placed. Specimens are packaged in a Carrying Case. Document Package with “Flaw Truth” documented by CAD drawings with a Standard Tolerance of (+ / -) 0.150” (4mm). The Standard Visual Examination Kit contains 20 flaws – types listed below.

Доставка импортных компонентов по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.

Оплата физическими и юридическими лицами безналичным расчетом.

Цена может измениться после запроса у поставщика!

Product Information

Kit Includes the following flaws:

#20 Crater Crack SV (surface stop-start area)

#32 Porosity SV (surface breaking)

#33 Porosity fillet (surface breaking)

#56 Incomplete Root Penetration SV

#59 Incomplete Groove Weld (crown area)

#70 Root Concavity SV

#71 Excess Root Penetration SV

#72 Misalignment Root & Crown SV

#73 Uneven Leg Length Fillet

#74 Excess Crown SV

#75 Excess Crown Fillet

#76 Concave Crown SV

#77 Concave Crown Fillet

#78 Undercut SV

#79 Undercut Fillet

#80 Overlap Fillet

#90 Weld Splatter SV

#91 Weld Splatter on Filler

Material: Carbon Steel
Kit contains 10 Specimens:
- (7) Plates @ 0.25T
- (3) Tee @ 0.25T
Flaws: 2 per specimen, 20 total
Doc Pack Includes C of C, CAD Drawings & Test Sheets
Carrying Case: 1 @ 6 x 16 x 20
Weight: ~35LBS
