Description
OPTICAL SYSTEM
- Infinity optical system
- Inward facing 5 position turret nosepiece w/ click stops
- 4x, 10X, 40X, 100x(oil) Plan Achro objectives
- 10X WF w/ 20mm FOV eyepiece
VIEWING HEAD
- Siedentopf head with 45° incline and 360° rotation
- Dual eyepiece diopter adjustment -8° to +5°
- Interpupillary adjustment distance of 48 mm to 75 mm
FOCUSING
- Coaxial coarse and fine focusing adjustment
- Tension adjustments
- Fine focus drive movement of 0.001 mm divisions
- Moving range: 24 mm
- Rack stop adjustment for protecting objective and specimen slides from accidental breakage
STAGE
- Double layer X/Y mechanical stage
- Size: 142 mm x 132 mm
- Movement Range: 75 mm x 50 mm
CONDENSER
- Adjustable Abbe Condenser w/ filter holder
- NA 1.25 with iris diaphragm
FRAME
- Rugged, durable metal frame construction
- Lightweight design makes it easy for students to move it around
- Carrying handle
- Power cord storage
- Rocker on/off switch
ILLUMINATION
- Eco-friendly and energy efficient 3W LED illumination
- Dimmer control for light intensity
Технические характеристики
| Condenser Type | Abbe Condenser NA1.25 with Diaphragm, Filter |
| Eyepiece | WF10X/20 mm |
| Product Type | Microscope |
| Material | Brass, Glass, Aluminum, Plastic |
| Warranty | 5 years optical and mechanical, 1 year electrical from date of purchase |
| Voltage | 110/220 V |
