Variable Area Flow Meters with 2 adjustable electrical contacts Body material — Transparent acrylic Connection material — Polypropylene, PVC ( on request ) Float material — Stainless steel with magnet Seal material — Silicone, FPM ( on request ) Thread connection — 1/2″ – 3/4″ – 1″ – 1 1/2″ – 2″ G depending on model Mounting — vertical Rated voltage — 24V Rated current — 3A
Технические характеристики
CharacteristicsTechnologyvariable-areaFluidfor liquidsInstallationverticalMaterialstainless steel, PVC, polypropyleneCommunicationwith electrical contactProtection levelIP65Volumetric flow rate
Max.: 750 l/min (198.1 us gal/min)
Min.: 0.5 l/min (0.1 us gal/min)
Process temperature
Max.: 60 °C (140 °F)
Min.: 0 °C (32 °F)
Process pressure
10 bar (145.04 psi)
Precision
4 %
