The high reliability anti vandal switch offer attractive, robust and durable switch, available with different bushing diameters(12 ~25mm), actuator shapes, available with LED illumination and engraving, Protection IP65 / IK09. This high reliability anti vandal switch features a easy clean, aesthetic look for high end products. Our high reliability anti vandal switch is popular for use in kiosk applications, ticket dispensers and industrial-type applications. Also comes in black anodized finish. • Variety of Colors • Momentary/ Alternate • Long life, high reliability High Reliability Anti vandal switchBasic Info. Protection: — Explosion-Proof, Waterproof, Dust-Proof Feature: — Mechanical Wiring: — Single Live Line Principle: — Resistive Application: — Electronics, Lighting, Industrial Type: — Composite Usage: — Control Button, Reset Button, Control Switch Certification: — ISO9001, CE, CCC Kind: Single-pole on-off Switch Specification: — CE, ROHS, REACH * Base voltage on LEDs: 1.8V @ 20mA for Red, Yellow and Orange LED colors / 2.8V @ 20mA for Blue, Green and White LED colors Technical Data • Max. Panel Thickness: : 0.394″ (10.0mm) • Terminal : Solder lug (2.8 x 0.5) • Contact Resistance : ≤50mΩ • Insulation Resistance : ≥1000mΩ • Dielectric Strengh : 2000VAC • Mechanical Life : 1,000,000cycles • Electrical Life : >50,000cycles • Contact Material : Silver Alloy • Torque : 5 ~ 14Nm • Operation Pressure : approx. 3 ~ 8N • Material : Actuator : Stainless Steel/ Anodized Aluminum • Body : Stainless Steel/ Anodized Aluminum • Base : PA
Технические характеристики
CharacteristicsTypetouchNumber of polesSPSTProtection levelwaterproof, vandal-proof, robust, IP65Mountingbuilt-inOther characteristicson/off, LED-illuminated, alternating current, industrial, non-illuminated, lighting, momentaryPrimary current
5 A
Voltage
250 V
Diameter / length
Min.: 12 mm (0.5 in)
Max.: 25 mm (1 in)
Operating temperature
Min.: -20 °C (-4 °F)
Max.: 55 °C (131 °F)
