Description
Benefits
- Fast, gentle drying
- Expansion rack technology ensures optimal heat transfer
- Direct heat transfer through large thermal conducting plates
- Safe work thanks to proven safety concept
- Also option of modular complete system with vacuum pump and pump chamber
- Shelves provide flexible placement
- and the interior is easy to clean
Important characteristics
- Temperature range: ambient temperature 10 °C to 220 °C
- Controller with digital display of pressure and temperature
- Program-controlled drying monitoring with automatic ventilation at end of process
- Internal data logger, measured values can be read out in open format via USB
- 1 aluminum expansion rack, can be custom-positioned
- Inert gas connection
- Shatterproof, spring-mounted safety glass panel
- Large viewing window with option of interior lighting
- Computer interface: Ethernet
- 2 relay outputs, 24 V DC (max. 0.4 A)
Optional equipment
- Touchscreen Controller — Graphical display of main process parameter
- Expansion racks — Choice of aluminum or stainless steel racks depending on the application requirements
- Analogue output for temperature and pressure signals — for external monitoring and evaluation of the process parameters, integration into in-house systems is possible
- Universal ventilation — Selection of different ventilation by air or inert gas
- Universal access port DN 40 — for the introduction of external measuring devices
- Multi Management Software APT-COM — Manage, record and document device parameters
- Services — extensive services ensure correct device function
Технические характеристики
| Controller Type | Controller with digital display of pressure and temperature |
| Temperature (Metric) | 9°C above ambient temperature to 220°C |
| Max. Shelf Load | 20 kg |
| Voltage | 100 to 120 V |
