Product Description #gap-5582488 { padding-top: 11px, } Memmert vacuum ovens effectively remove moisture, gas and other volatile chemicals while preventing reactions. These vacuum ovens have been trusted in the manufacturing of implantable medical devices, packaged food products, essential oils, semiconductors and epoxies. Industrial, food processing and pharmaceutical industries choose Memmert vacuum ovens for shorter heating and processing times, aluminum thermoshelves and precise temperature control. Features include: Temperature range up to +200 C Vacuum control range: 5 mbar up to 1100 mbar 3 model sizes (29 to 101 liters volume) 1 model variant: TwinDISPLAY (PLUS) Vacuum pump (PMP) sold as an accessory Inert gas connection for VO 49 & 101 #gap-351496001 { padding-top: 20px, } #image_772135460 { width: 30%, } Reduced Processing Time Memmerts exclusive digitally-controlled vacuum cycles oscillating pressure under controlled conditions significantly reducing drying time. #image_1206415956 { width: 30%, } Energy Savings Memmerts demand-oriented pump control ensures significant energy-saving with 70% lower energy consumption in ramp operations. #text-3254261571 { text-align: center, } #gap-663292327 { padding-top: 15px, } #col-1557865999 > .col-inner { margin: 0px 0px -18px 0px, } #image_1301540257 { width: 84%, } Multi-level Sensing and Heating Memmerts intelligent thermo-shelves provide direct heating with separate sensors that react precisely to different loads or humidity and maintain a constant set temperature. #text-1033524776 { font-size: 1.1rem, text-align: left, } #image_586952046 { width: 84%, } Stainless Steel Construction Stainless steel construction inside and out. Memmert appliances feature welded/ rounded edges within the stainless steel chamber for a hygienic and easy-to-clean interior. #text-3948660185 { font-size: 1.1rem, } #gap-1392312858 { padding-top: 10px, } Technical Specifications #gap-958750584 { padding-top: 15px, } Appliance size 29 49 101 Appliance width D1 [mm] 550 550 710 Appliance height E1 [mm] 600 680 760 Appliance depth F1 [mm] 400 480 550 Depth of door lock [mm] 38 Chamber width A1 [mm] 385 385 545 Chamber width B1 [mm] 305 385 465 Chamber width C1 [mm] 250 330 400 Base Width G [mm] 529 529 689 Height H [mm] 450 290 130 Depth I [mm] 383 463 533 Chamber volume [litres] 29 49 101 Weight [kg] 62 74 100 Power [W] 820 2020 2420 Current consumption [A] 230 V, 50/60 Hz 3.6 8.8 10.5 max. number of thermoshelves Standard 1 2 2 Premium 2 4 4 max. load per Thermoshelf [kg] 20 max. load per appliance [kg] 60 80 150 Temperature Adjustment range 20 C to 200 C Adjustment precision 0.1 K Operating temperature range 5C above room temperature up to 200C Pressure Adjustment range 5 mbar 1100 mbar Adjustment precision 1 mbar Leak rate &le, 0.5 x 10-2 mbar 1/sec #text-1011612639 { font-size: 0.75rem, } #col-1104741046 > .col-inner { margin: 0px 0px -7px 0px, } #image_1955216457 { width: 100%, } #gap-2109076481 { padding-top: 20px, } #text-3938702955 { font-size: 0.95rem, } #image_1876376783 { width: 65%, } #image_676846701 { width: 65%, } #col-1363192018 > .col-inner { margin: 0px 0px 7px 0px, } #row-647965175 > .col > .col-inner { padding: 0px 0px 0px 0px, } SCHEDULE A free CONSULTATION #image_1280094792 { width: 100%, } #gap-1568103899 { padding-top: 30px, } #text-1776863986 { font-size: 1rem, } The more complex twin display allows users to control every aspect of equipment functionality. Even complex processes such as multiple overtemperature protection, visual and acoustic alarm as well as automated alarm messages can be programmed quickly and easily. #text-3854608855 { font-size: 1rem, text-align: center, } #gap-94781906 { padding-top: 21px, } #gap-1712543597 { padding-top: 15px, }
Технические характеристики
Technical Specifications
Appliance size | 29 | 49 | 101 | |
Appliance width D1 [mm] | 550 | 550 | 710 | |
Appliance height E1 [mm] | 600 | 680 | 760 | |
Appliance depth F1 [mm] | 400 | 480 | 550 | |
Depth of door lock [mm] | 38 | |||
Chamber width A1 [mm] | 385 | 385 | 545 | |
Chamber width B1 [mm] | 305 | 385 | 465 | |
Chamber width C1 [mm] | 250 | 330 | 400 | |
Base | Width G [mm] | 529 | 529 | 689 |
Height H [mm] | 450 | 290 | 130 | |
Depth I [mm] | 383 | 463 | 533 | |
Chamber volume [litres] | 29 | 49 | 101 | |
Weight [kg] | 62 | 74 | 100 | |
Power [W] | 820 | 2020 | 2420 | |
Current consumption [A] 230 V, 50/60 Hz | 3.6 | 8.8 | 10.5 | |
max. number of thermoshelves | Standard | 1 | 2 | 2 |
Premium | 2 | 4 | 4 | |
max. load per Thermoshelf [kg] | 20 | |||
max. load per appliance [kg] | 60 | 80 | 150 | |
Temperature | Adjustment range | 20 °C to 200 °C | ||
Adjustment precision | 0.1 K | |||
Operating temperature range | 5°C above room temperature up to 200°C | |||
Pressure | Adjustment range | 5 mbar — 1100 mbar | ||
Adjustment precision | 1 mbar | |||
Leak rate | ≤ 0.5 x 10-2 mbar 1/sec |
