The Vacu-Storr high vacuum storage containers (desiccators) were developed to store materials which are sensitive to dust, moisture, oxygen and other gases found in the environment. The Vacu-Storr is capable of pumping down to vacuum levels of 10-4mbar. With a higher conductance valve and capable pump even 10-6 mbar is achievable. The clean design of these high-tech desiccators with soda-lime glass containers, nickel-plated aluminium cap, viton vacuum seal and metal valve with PTFE shaft seal is capable of holding a vacuum for 5 years to 0.1 bar (atmosphere). Vacuum connection for pump-down is 1/4″ (6.35mm) barb fitting. Shielded with protective plastic mesh for implosion protection. Available in four sizes:
Cat. No.
Size
Volume (mL)
ID (mm) OD (mm) Inside height (mm Total height (mm) V25-0040 Small 40 41 54 30 95 V25-0320 Medium 320 76 85 71 140 V25-0680 Large 680 76 90 150 190 V25-3800 X-large 3800 (1 gallon) 140 153 305 350
Storage applications:
- Moisture sensitive parts such as integrated circuits, rare earth elements, steel, metals
- Superconducting materials
- Oxygen reactive materials such as magnesium and lithium
- Elemental standards for EDS, WDS, EPMA, micro-XRF
- SEM/TEM samples
- Pre-cleaned parts
- Shipping sensitive parts
