Технические характеристики
- Transmission 185–2100 nm
- Size 15 x 15 x 15 mm
- Material UV Grade Fused Silica
- Apex Angle 69.06°
- Antireflection Coating Uncoated
- Surface Quality 40-20 scratch-dig
- Surface Flatness &le,&lambda,/10 at 632.8 nm over the clear aperture
- Clear Aperture &ge,90% of face
- Chamfers 0.5 mm face width
- Chamfers Angle Tolerance 45° maximum
- Cleaning See How to Clean Optics
