Wrapping machines with mechanical brake that work with all types of stretch film. Easy to operate, with perfect results for pallet wrapping. MAIN CHARACTERISTICS • The film distributor is moving inside the metal tower. The stretch film is protected from polution and mechanical influences. Increased safety for the operator. • Adjustment of the film tension • Soft start and stop of the turntable • Step-less control of the speed of the film distributor independent from the turntable rotation speed – control of flim overlapping, possibility to optimize the film consumption • Programming of the wrapping layers at the bottom and at the the top of the pallet • Three main programs: single, cross-wrapping and splash-proof • Automatic control of the wrapping height by a photocell • Possibility to interrupt the wrapping process and restarting from the same place (pause function) • Additional options: Load stabilizer, access ramp, pit mounting frames
Технические характеристики
CharacteristicsTypeturntableOperating modesemi-automaticProduct applicationsfor building materials, for bricksOther characteristicsstretch filmHeight
2,400 mm (94 in)
Maximum wrapping height
Max.: 2,400 mm (94.49 in)
Min.: 50 mm (1.97 in)
Maximum pallet length
Max.: 1,200 mm (47.24 in)
Min.: 1,000 mm (39.37 in)
Maximum pallet width
1,200 mm (47.24 in)
Maximum pallet weight
2,000 kg (4,409.25 lb)
Table diameter
1,650 mm, 2,000 mm (64.96 in)
Rotational speed
11 rpm (69 rad.min-1)
