Semi-automatic luggage wrapper with stretch film. The model Baggy Wrap 900 B is a semi-automatic stretch wrapping machine for rectangular luggage. It is equipped with a digital lcd control panel that allows, in a very simple and functional way, to regulate the programs and the wrapping parameters easily. Machine controlled by PLC. Parameters adjustable by control panel: Luggage number of rounds in bottom Luggage number of rounds in top Adjustable turntable speed from 0 to 20 rpm Carriage ascending and descending speed Photoeye reading delay adjustable Function Man/Aut. Features Machine structure in painted steel sheet Film carriage by transmission chain Maximum wrapping height: 1200 mm Environmental humidity conditions: &le, 90% Operating Temperature range: +0 C to + 40 C Machine controlled by PLC with digital text display Film carriage fall protection system Motorized pre-stretch set at 250% with possibility to interchange pre-stretch ratios (150, 200, 250%) Ermegency stop in compliance with CE regulations Lateral holes for forklifting of the machine Inverter for soft start and indexed stop of the turntable
Технические характеристики
CharacteristicsTypeturntableOperating modesemi-automaticProduct applicationscase, airport luggageOther characteristicsstretch filmMachine weight
150 kg (330.69 lb)
Rotational speed
Min.: 0 rpm (0 rad.min-1)
Max.: 20 rpm (126 rad.min-1)
Power
1.5 kW (2.04 hp)
