Description
The Tali Image-Based Cytometer is a 3-channel (bright field, green fluorescence, red fluorescence) benchtop assay platform that uses state-of-the-art optics and image analysis to perform assays for cells in suspension, including GFP and RFP expression, apoptosis, cell viability (live, dead, and total cells), cell cycle, and cell counting assays. It is compatible with a wide variety of eukaryotic cells. In addition to the bright field channel, the Tali® Image-Based Cytometer features two fluorescent channels (green and red), enabling it to simultaneously count green or red fluorescent stains, as well as cells expressing GFP and RFP.
Specification:
- Instrument type: Benchtop cell counter and suspension cell-based assay platform
- Dimensions (W x D x H): 11.5 x 17.5 x 11.5 in.
- Weight: 19.4 lbs
- Operating power: 100–240 VAC, 2.5 A, 120 V
- Frequency: 50/60 Hz
- Electrical input: 12 VDC, 13 A
- Installation site: Indoor use only, Class A environments, pollution degree 2
- Operating temperature: 10 – 40°C
- Operating humidity: <, 80% (non-condensing)
- Processing time: 10 seconds to 2 minutes, depending on the number of fields captured
- Sample concentration range: 1 x 10^5 – 1 x 10^7 cells / mL
- Particle/cell diameter range: 5-60 µm
- Required sample volume: 25 µL
- Firmware: Tali Image-Based Cytometer Firmware
- USB drive: 4 Gigabyte
- Optics: 3 channels (bright field, green fluorescence, red fluorescence)
- Excitation: Green channel LED (458 ± 20 nm), Red channel LED (530 ± 20 nm)
- Green channel filter: 466/40 EX, 495 LP Di, 525/50 EM
- Red channel filter: 543/22 EX, 580 LP Di, 585 LP EM
- Camera: 1.3 Mega pixels, 4x objective, 4x or 16x digital zoom
