Технические характеристики
| Type number | C14120-20P |
|---|---|
| Imaging device | Scientific CMOS image sensor |
| Effective no. of pixels | 4608 (H) × 2592 (V) |
| Cell size | 5.5 μm (H) × 5.5 μm (V) |
| Effective area | 25.344 mm (H) × 14.256 mm (V) |
| Full well capacity | Standard Full Well Capacity mode: 1000 electrons High Full Well Capacity mode: 38 000 electrons |
| Readout speed | 121 frames/s (at full resolution) |
| Readout noise | Standard Full Well Capacity mode：1.5 electrons median Standard Full Well Capacity mode：2.0 electrons rms High Full Well Capacity mode：2.2 electrons median High Full Well Capacity mode: 2.7 electrons rms |
| Exposure time | Standard Full Well Capacity mode: 6.304 μs to 1 s High Full Well Capacity mode: 50.432 μs to 1 s |
| Cooling temperature | Forced-air cooled (Ambient temperature: +25 ˚C): +20 ˚C Water cooled: +20 ˚C |
| Dark current | 15 electrons/pixel/s (Typ.) : Air cooled (cooling temperature: +20 ˚C) |
| Dynamic range | Standard Full Well Capacity mode: 650 : 1 High Full Well Capacity mode: 17 000 : 1 |
| Sub-array | Yes |
| Binning | 2×2, 4×4 |
| External trigger input | Edge trigger, Global reset edge trigger, Level trigger, Global reset level trigger, Synchronous readout trigger, Start trigger |
| External trigger signal routing | SMA |
| Trigger delay function | 0 s to 10 s in 1 μs steps |
| Interface | CoaXPress (Quad CXP-6) |
| A/D converter | Standard Full Well Capacity mode: 12 bitHigh Full Well Capacity mode: 16 bit |
| Power consumption | Approx. 200 VA |
| Ambient operating temperature | 0 ˚C to +40 ˚C : Forced-air cooled (With no condensation) |
| Ambient operating humidity | 30 % to 80 % |
