Trelleborg Singlegate T-VET -grommets are for leading through both low and medium power current cables as well various types of tubing. The grommets are suitable for indoor and outdoor applications. The grommets its to openings made with dimensions of PG. Model T-VET has new double seal design where top side of the grommet is closed and is therefore possible to use as plug also. Trelleborg Singlegate T-VET -grommets have alternative models for cables between diameters of 3 mm up to 35 mm. Wall thickness can be between 1 to 4 mm. The design gives IP67 protection against dust and strong jets of water and also against effects of immersion between 15 cm and 1 m. Trelleborg Singlegate T-VET -grommets are available as standard of TPE-materials on table below. As request also other colours and materials like conductive EMC-material are available. Trelleborg Singlegate T-VET-grommets are inspected and certified by SGS.
Технические характеристики
CharacteristicsMaterialTPETypemembrane, pass-through, with sealing lipOther characteristicsIP67Diameter
Max.: 35 mm (1.38 in)
Min.: 3 mm (0.12 in)
