Working Stroke [mm]: — 0 Throat [mm]: — 250 Troat [mm]: — 100 T-slot [mm] similar to DIN 650: — 12 Ram bore Øxdepth [mm]: — 10H7 x 30 Ram Ø [mm] / Surface F [mm²]: — 30 Space required CxG [mm]: — 200 x 450 mäder toggle presses only produce their rated force at the end of the stroke, the bottom dead centre (BDC). In doing so, the high working pressure of the press is achieved using the toggle mechanism with a relatively low effort (approximately 150N) on the part of the user. Toggle presses are therefore used where the full force of the press is only required over a short distance at the end of the working stroke, e.g. in assembling, punching, riveting, stamping, gluing etc. Standard throats of 63mm, 100mm and 250mm allow a broad selection of partsto be processed. Depending of the model daylight can be adjusted steplessly from 43 mm to 375mm. mäder manual toggle presses can be upgraded with various extras which enhance the functionality of the press. The round ram of mäder pressen is characterized by high sturdiness, ground surface and precise ram bore. Tools can be fixed securely in the ram bore by means of a fixation screw. Round rams of mäder pressen are either guided in precision honed bores or in precise Teflon bushings. The extra powerful hand-operated toggle presses of the APK T 3 and APK T 4 ranges are especially suitable for the frequently changing applications in model making and in the workshop. Their high forces of up to 30 kN enable them to be flexibly used for widely differing applications.
Технические характеристики
CharacteristicsOperationmanual, screwFunctionstamping, punching, riveting, for gluingStructuretoggle, ram, round ramControlhand-operatedOther characteristicsshop, fixedForce
15 kN
Stroke
60 mm (2 in)
Table width
200 mm (8 in)
Table length
200 mm (8 in)
Weight
58 kg (128 lb)
