With inverter technology, the GYSARC 220 FV CEL is a single-phase 220 A MMA power source that meetsthe professionals’ requirements. Designed around reinforced electronics, this workstation can easily weld cellulosic, rutile or basic electrodes. It is also equipped with the TIG lift (DC) process which ensures high quality weld beads, even on thin sheets. Robust and versatile, the GYSARC 220 FV CEL offers the user great welding comfort and maximum productivity. Welds basic, rutile and cellulosic electrodes up to 0 5 mm thanks to 2 MMA modes : • — MMA Standard • — Adjustable Puise MMA : idéal for welding in the vertical upright position. • — TIG Lift : ignition by simply touching the workpiece. TIG welding help : Automatic arc fading • — Adjustable TIG Puise : facilitâtes the welding of very thin sheets (0.3 mm) and increases bead pénétration Integrated welding helps in MMA Adjustable Hot Start : generates an overcurrent at start-up to facilitate ignition and reduce welding defects. Adjustable Arc Force : regulates arc length déviations and offers comfort to the welder. Antisticking : prevents the electrode from sticking if it cornes into contact with the workpiece. Reinforced security VRD (Voltage Réduction Device) : lowers the no-load voltage (
Технические характеристики
CharacteristicsTechniqueTIG, MMAConsumableselectrodePower supplysingle-phaseOutput currentDCOther characteristicsinverterCurrent
90 A, 130 A
