Thermocouple (TC) temperature assembly for higher flow velocities and pressures • Thread connection • DIN-style based on form 7, barstock thermowell with straight tip • -40…+600°C / +1100°F The OPTITEMP TCA-TS36 is a threaded thermocouple (TC) assembly with a straight barstock thermowell (based on form 7). The temperature assembly for advanced requirements is used when the strength of welded multipart thermowells is not sufficient and a high mechanical stress resistance of the thermowell is required. It is therefore particularly suitable for temperature measurement in pipes, tanks or reactors at higher flow velocities and pressures (e.g. in the petrochemical or oil and gas industry). The TC sensor is designed for process temperatures up to +600°C / +1100°F. The OPTITEMP TCA-TS36 features a modular design with a threaded standard neck tube that can be exchanged easily, even under operating conditions. This makes the temperature assembly very flexible. If it has been damaged from the outside, servicing can be carried out without process shut down. The thermocouple assembly can be combined with most thermowells. It is available with ATEX and IECEx approvals. Product highlights • Temperature measurement of liquids, gases and steam • Modular design: threaded standard neck tube for easy exchange under operating conditions • Thermowell material: 1.4404 / 316L or 1.4571 / 316Ti • Standard or customised lengths • Different connection heads available (IP54…IP68) • With optional temperature transmitter • Available as intrinsically safe (Ex i) and flameproof (Ex d): ATEX, IECEx Typical applications • Applications with advanced requirements
Технические характеристики
CharacteristicsTechnologythermocoupleMountingthreadedProtection levelATEX, intrinsically safe, IP68Applicationsfor liquids, for gas, for pipes, for the petrochemical industryOther characteristicswith thermowell, with extension tubeTemperature
Max.: 600 °C (1,112 °F)
Min.: -40 °C (-40 °F)
