Thermocouple (TC) temperature assembly for standard applications • Thread connection • DIN-style based on form 2G, welded multipart thermowell with straight tip • -40…+600°C / +1100°F The OPTITEMP TCA-S12 is a threaded thermocouple (TC) assembly with a straight welded multipart thermowell (based on form 2G) and neck tube. The industrial temperature assembly for standard applications can be screwed directly to the process pipe or tank. It is suitable for temperature measurement of gases and liquids up to +600°C / +1100°F. The TC sensor can be used at low to medium pressures and flow velocities. It is available with ATEX and IECEx approvals. Product highlights • Temperature measurement of liquids and gases • Thermowell material: 1.4404 / 316L or 1.4571 / 316Ti • Standard or customised lengths • Different connection heads available (IP54…IP68) • With optional temperature transmitter • Available as intrinsically safe: ATEX, IECEx Typical applications • Standard applications with low to medium pressures and flow velocities • Temperature measurement in pipes and tanks • Suitable for applications where assemblies complying with DIN standards are required • Basic measuring tasks in various industries: • Chemical and petrochemical • Oil and gas • Power generation • Machinery and apparatus / OEM • Iron and steel • Pulp and paper Product details Alternative product categories : TC probe, Thermocouple probe Technical data Measurement principles : Thermocouple (TC) Measured media : Gases, Liquids Measuring point : Pipe, Tank Temperature sensor connection type option : Ceramic terminal block, Flying wires, Temperature transmitter Measuring insert replaceable : Yes
Технические характеристики
CharacteristicsTechnologythermocoupleMountingthreadedProtection levelATEX, intrinsically safe, IP68Applicationsfor liquids, for gas, for pipesOther characteristicswith thermowell, with extension tubeTemperature
Max.: 600 °C (1,112 °F)
Min.: -40 °C (-40 °F)
