Thermocouple (TC) temperature assembly for high temperature applications • Compression fitting or sliding flange connection • Welded multipart thermowell with straight tip • -40…+1150°C / +2100°F The OPTITEMP TCA-P62 is a plug-in thermocouple (TC) assembly with a straight welded multipart thermowell made of 1.4762 / AISI 446 or 1.4767 / Kanthal AF. The high temperature assembly is particularly suitable for temperature measurement of flue and combustion gases up to +1150°C / +2100°F as well as in applications where the thermowell is exposed to mechanical abrasion. It can be used at low operational pressures. The OPTITEMP TCA-P62 can be mounted to pipes, stacks and ducts by a gas-tight compression fitting or a sliding flange. Product highlights • High temperature measurement of gases • Thermowell material: 1.4762 / AISI 446 or 1.4767 / Kanthal AF • Standard or customised lengths • Different connection heads available (IP54…IP68) • With optional temperature transmitter • Typical applications • High temperature measurement of flue gases or other furnace exhaust gases at ambient or low operating pressures • Suitable for combustion process applications in various industries: • Power generation • Iron and steel • Chemical • Rubbish incineration • Basic materials Product details Alternative product categories : TC probe, Thermocouple probe Technical data Measurement principles : Thermocouple (TC) Measured media : Gases Measuring point : Pipe Temperature sensor connection type option : Ceramic terminal block, Flying wires, Temperature transmitter Measuring insert replaceable : Yes Sensor mounting : Plug-in Thermowell diameters : Ø19 mm / 0.75′, Ø22 mm / 0.87′
Технические характеристики
CharacteristicsTechnologythermocoupleMountingflange, plug-inApplicationshigh-temperature, for exhaust gas, flue gasOther characteristicswith thermowellTemperature
Max.: 1,150 °C (2,102 °F)
Min.: -40 °C (-40 °F)
