Features:
- Frequency up to 160MHz, 15 digits or 1µHz resolution
- Arbitrary waveforms up to 16bits at 800MSa/s
- Wideband noise generator | high resolution pulse generator
- Comprehensive internal/external digital and analog modulations
- Two identical channels with phase control, coupling and tracking
- USB and LXI compliant LAN interfaces, plus optional GPIB interface
Accessories:
- AC power cable appropriate to country of sale
- Printed Quick Start guide in English, French, German, Italian and Spanish
- Full Operating Manual as PDF (English) on CD
- Waveform Manager Plus software on CD
- Large number of pre-built arbitrary waveform on CD
- IVI driver, combined LabView/LabWindows CVI driver, and USB driver on CD
Specifications:
- Frequency Range: 1µHz to 80MHz
- Frequency Resolution: 1µHz, 14 digits
- Output Level: ≤ 80MHz 10mVp-p to 5Vp-p into 50Ω, N/A
- 80MHz two channel generator
- 90V to 264V AC input
The TGF3082 is a function/arbitrary generator that offers signal generation capability up to 160MHz on two identical full performance channels that can operate independently or in coupled or tracking modes. Precise channel to channel phase control with a resolution of 0.001° is provided.
Технические характеристики
| Manufacturer | Thurlby Thandar Instruments |
|---|---|
| Condition | New |
| Frequency | 80 MHz |
