Applications Crane systems and hoists Industrial weighing technology Machine building and plant construction, manufacturing automation Theatre and stage construction Chemistry and petrochemistry Special features Measuring ranges 0 … 1 kN up to 0 … 100 kN Corrosion-resistant stainless steel design Integrated amplifier High long-term stability, high shock and vibration resistance Good reproducibility, simple installation Tension/compression force transducers are designed for static and dynamic measurement tasks in the direct flux of force. They determine the tension and compression forces in a wide scope of applications. Tension/compression force transducers of this series are often used in hoist and crane systems, as well as for special machine constructions, in laboratories and stage systems. Appropriate technical and regional approvals are available as an option. These force transducers are made of high-strength, corrosion-resistant stainless steel 1.4542, which is particularly suitable for their application areas. The standard active current and voltage outputs are available as output signals (4 … 20 mA/0 … 10 V). Redundant output signals and CAN protocols are possible. These force transducers are part of our certified product ELMS1 overload protection (DIN EN ISO 13849-1 with PL d/Kat. 3 and SIL 2).
Технические характеристики
CharacteristicsTypetension/compressionApplicationsweighingOther characteristicscorrosion-resistant, stainless steelRated force
Max.: 100 kN
Min.: 0 kN
