Double-deck High Low Temperature Test Chamber provides a constant high and low temperature environment condition ranges from -40°C to 150°C (Available for customized design). It is widely used to test the thermal performance of various products and components. The two test cabinets work independently, providing high efficiency and performance for laboratory testing. Furthermore, the additional explosion-proof function enables this test chamber to be combined with the charge-discharge test, providing a temperature environment for various battery performance testing. Features 1. PLC Control, programmable, remote computer control 2. Heating System 3. Refrigeration System 4. Forced Internal Circulate System 5. Fume Exhaust System 6. Explosion-proof System Standards • IEC 60068-2-1:2007: Low temperature testing • IEC 60068-2-2:2007: High temperature testing • GJB 150.3-1986: High temperature testing • GJB 150.4-1986: Low temperature testing • GB/T 2423.1-2008: Low temperature testing • GB/T 2423.2-2008: High temperature testing • GB/T 31485-2015: Safety requirements and test methods for electric vehicles’ power batteries Performance parameters: Structure Mode: An integral structure with upper and lower cabinets. Temperature Fluctuation: ±0.3℃ Temperature Uniformity: ≤±2℃ (No load, constant state) Observation Window: Explosion-proof glass with explosion-proof membrane Cooling Mode: Air cooling Controlling Mode: Touch screen programmable control PLC, with USB interface, with RJ485 .interface can be connected to computer control, special network control software, convenient remote monitoring, data acquisition
Технические характеристики
CharacteristicsTypetemperatureApplicationsfor batteryConfigurationon castersOptions and accessoriesstainless steel, low-temperature, for high temperatures, explosion-proofTemperature
Max.: 150 °C (302 °F)
Min.: -40 °C (-40 °F)
Length
1,700 mm, 1,950 mm (66.93 in)
Width
1,300 mm, 1,500 mm (51.2 in)
Depth
1,700 mm, 1,800 mm (67 in)
Power
12,000 W
