Description
Features:
The GPFD- General Purpose Freeze Dryer is available in 25 and 35 Liter configurations. Condenser refrigeration packages of -53 or -85C allow you to configure the most economical system for your products. The GPFD is available in 2 to 5 shelf configurations with optional programmable heat.
The GPFD is ideal for bulky products such as artifacts/documents where low energy input is required and long freeze-drying cycles are common. It is also ideal for large quantities of very low moisture products.
- Mobile, free-standing design
- Choice of refrigeration systems with temperatures of -53 or -85C
- 2 to 5 shelves
- Intellitronics Controller to monitor your cycle from anywhere you receive email
Benefits:
- Mid-cycle defrost option for drying larger items
- Visually monitor product progress through acrylic door
- Large batch processing in a single run with 25 or 35-liter condenser capacity
- Accommodate a wide variety of product solvents with temperatures to -85C
- Long equipment life, chamber configured of 304 stainless steel
- Easy install
Specifications:
- Maximum low condenser temperature (°C): -53°C
- Condenser capacity in 24 hrs: 14 L
- Condenser capacity total: 25 L
- Condenser surface area: 506 in² (3264 cm²)
- Construction: 304 stainless steel chamber and condenser
