The new PELCO Embedding Studio introduces features that improve efficiency and functionality over existing embedding centres on the market, meeting the needs for both high and low volume histology laboratories. It is built with the latest innovations on top of trusted technology enhancing tissue embedding workflow and is specifically designed to accommodate the embedding of large super mega tissue blocks. The PELCO Embedding studio comprises four components, PELCO Dispenser, PELCO Warmer, PELCO Chiller and PELCO Freezer. Available as a complete PELCO embedding studio or some modules available separately.
Features:
- Continuous embedding up to 260 standard blocks or 78 Super Mega blocks
- 20 standard blocks or 6 Super Mega blocks per tray ready for sectioning
- PELCO Freezer module allows optimisation of PELCO Chiller plate
- Super Mega blocks and normal sized blocks may be transferred to complete polymerisation without filling the PELCO Chiller plate
- Thermoelectric cooling technology for longer instrument life and regulatory compliance
Available:
Product Description Specifications ETP13000
The PELCO embedding studio includes Dispenser, Warmer, Chiller and Freezer modules and allows for continuous embedding up to 260 standard blocks or 78 Super Mega blocks. Includes 10 standard transfer trays
Dimensions (D x W x H): 700 x 1520 x 337mm
Weight: 66.2kg
Power Supply: AC 100-240V, 15/10A, 50/60Hz
ETP13000-10
The PELCO Chiller is cooled by thermoelectric cooling technology (TEC) with a temperature range of -5°C to 5°C and can accommodate up to 50 standard size or 12 Super Mega embedding moulds.
Operates with or with out the PELCO embedding studio
Dimensions (D x W x H): 700 x 356 x 337mm
Weight: 19.1kg
Temperature Range: -5° C to 5° C
Power Supply: AC 100-240V, 15/10A, 50/60Hz
ETP13000-40
The PELCO Freezer is cooled by TEC. It has five shelves which can accommodates two transfer trays each and has a capacity of up to 210 standard paraffin embedded tissue blocks or 60 Super Mega paraffin embedded tissue blocks.
Includes 10 standard transfer trays
Operates with or with out the PELCO embedding studio
Dimensions (D x W H) 585 x 450 x 360mm
Weight: 19.1kg
Temperature Range: -5° C to 5° C
Power Supply: AC 100-240V, 15/10A, 50/60Hz
ETP13000-41
Transfer tray, flat.
ETP13000-42
Transfer tray, standard.
ETP13000-43
Transfer tray, Super Mega moulds.
ETP4013
The Paraffin Scraper is highly-durable and can be used to remove paraffin wax from the PELCO Embedding Studio and work station surfaces.
ETP13000-20-1
Silicone rubber collection tray collects waste paraffin from the PELCO Dispenser. These silicone rubber trays are heated to prevent the buildup of polymerised paraffin and allow easy removal of the waste paraffin.
