Flexible storage tanks are the ideal solution for long or medium-term storage for your liquid fertilizers (nitrogenated or sulfurous solutions). To meet your needs, our flexible storage tanks are fitted with connections and valves for optimized filling and emptying. This flexible storage system must be used with its own spill retaining structure using a wall or metal frame. It can be installed indoors or outdoors. APPLICATIONS Storage of nitrogenated liquid fertilisers ADVANTAGES Use •Economic •Environmentally friendly •Completely closed (no odours) Safety •Constant volume, no evaporation •Protected from rain water •Unique weld seam reinforcement Handling •No need for a building permit •Quick and easy deployment •Adaptable to your space DETAILED INFORMATION •Material: high resistance 1300gr/m2 cloth •Coating: double-sided PVC •Dimensions: standard and custom made on request •Assembly: high-frequency welding with a unique edge protection process •Tensile strength (ch/tr): 300 daN/5cm •Tear resistance (ch/tr): 300 daN/5cm •Temperature resistance: -30°C to + 70°C •Adherence (ch/tr): 10 daN/5cm •Accessories: o1 DN 140 welded vent to screw-in with gas release valve o1 DN 80 elbow overflow with symmetrical connector and cap o1 DN 50 PPG quarter-turn guillotine valve assembly + DN 50 symmetrical connector and cap o4 reinforced corners o1 repair kit othermal valve protector
Технические характеристики
CharacteristicsFunctionstorageProduct applicationsfor agricultural and vineyard effluentsMaterialfabricTypeflexibleOther characteristicshorizontalCapacity
Max.: 100 m³ (3,531.5 ft³)
Min.: 30 m³ (1,059.4 ft³)
