Dental Steam Sterilizer Autoclave Medical Sterilization 14L. Safety Valve. Uses The Vapor Power Emissions Cold Air, 2 Times.The Sterilize Time is 25 Minutes. Long-lasting Use.
- Water Supply System: Manual give the water.
- Safety Valve: Automatic discharge in excess of standard value.
- Temp and Press Display: Pressure gauge
- Disinfection Principle: Uses the vapor power emissions cold air/2 times.
|
- Plug in the power cord.
- Shut exhaust needle valve in the Close (clockwise)°.
- Adding about 800 ml of distilled water. Close the door cover, tight the rotate handle.
- Start the timer knob to 121 ℃ position. Sterilization is working.
- Sterilization is complete, please be sure to open the exhaust needle valve firstly (inverse clock direction).
- Wait for the pressure gauge pointer to zero, opened the door cover.
|
- Every time sterilization, must add about 800 ml of distilled water.
- Use a separate socket (confirm the socket of the output voltage).
- Pressure gauge pointer in the red areas, please be sure to first Open the exhaust steam of the needle valve.
|
| Chamber Capacity: | Ø25×D28CM (Ø9.84×D11.02inch) |
| Inside Capacity: | 14 Liters |
| Material: | Stainless steel #304 |
| Outside Size: | 46.5*35*36 CM |
| Packing Size: | 51*39*40 CM |
| G.W: | 15KGS |
| Sterilizer Temperature: | 121℃ |
| Sterilize Pressure: | 0.12Mpa |
| Sterilize Time: | 25Min |
| Power: | 900W AC110V/8A |
| Main Unit: | 1pc |
| Plate: | 3pcs ( Size:201*136*21 mm) |
| Shelf: | 1pc |
| Take Plate Tool: | 1pc |
| Steam Exhaust Pipe: | 1pc(1 meter length) |
Технические характеристики
| Chamber Capacity: | Ø25×D28CM (Ø9.84×D11.02inch) |
| Inside Capacity: | 14 Liters |
| Material: | Stainless steel #304 |
| Outside Size: | 46.5*35*36 CM |
| Packing Size: | 51*39*40 CM |
| G.W: | 15KGS |
| Sterilizer Temperature: | 121℃ |
| Sterilize Pressure: | 0.12Mpa |
| Sterilize Time: | 25Min |
| Power: | 900W AC110V/8A |
