The experience accumulated over more than 60 years as well as ongoing research, the GEMV boiler, as a consequence of its insulation of great thickness and high density has very little loss from radiation. Electric medium voltage (4160 — 6600 V) Good accessibility for maintenance and checks due to the removable inspection box and removable panels. High amount of steam thanks to the steam chamber’s considerable volume and height, together with the addition of the interior drip trap. Low charge ohmic resistance made of stainless steel, encapsulated and plated, completely submerged make the GEMV a steam generator with unsurpassable heat transfer. Power scaling from 1 to 4 stages makes GEMV a steam generator that is flexible and modulating in supplying steam. Upon request, the GEMV boiler may be supplied with an ATTSUTROL electric control cabinetwith built in automation. Twenty-four or seventy-two hour surveillance. The GEMV boiler, thanks to the single startup control, incidence indicators automatic blocking against erroneous maneuvers and a panel with summarized maintenance instructions makes it very reliable and comprehensible to the boiler operator. It provides a low heat loss from radiation thanks to the insulation of great thickness as well as front and back door insulation. Thermal insulation is composed by a thick layer of low conductivity and high density material, covered by a stainless steel metallic enclosure. The boiler could be optionally equipped with PLC with HMI including different communication protocols such as Modbus, Profibus, etc., enabling boiler integration in any industrial process.
Технические характеристики
CharacteristicsProductsteamPower sourceelectricOther characteristicsindustrialPower
Max.: 10,000 kW
Min.: 2,000 kW
Steam production
Max.: 15,000 kg/h (33,069.34 lb/h)
Min.: 3,000 kg/h (6,613.87 lb/h)
