Standard RT Kit (Radiographic Testing)

The Flawtech Radiographic Kit Contains: 8 Plates, 1 Pipe & 1 Tee / Carbon Steel. Each specimen contains 2 “REAL FLAWS,” randomly placed Actual X-Ray film is provided for each specimen. Specimens are packaged in 2 Carrying Cases. Document Package with “Flaw Truth” documented by CAD drawings with a Standard Tolerance of (+ / -) 0.150” (4mm). The Standard Radiographic Examination Kit contains 20 flaws – types listed below.

Доставка импортных компонентов по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.

Оплата физическими и юридическими лицами безналичным расчетом.

Цена может измениться после запроса у поставщика!

Product Information

Kit Includes the following flaws:

#12 Root Crack in SV

#14 Centerline Crack SV (Surface breaking)

#15 Centerline Crack, SV (Sub-surface)

#30 Porosity SV / DV

#31 Porosity Fillet (sub surface)

#34 Single Gas Pore SV

#36 Slag Inclusion SV (root area)

#37 Slag Inclusion SV (weld groove area)

#38 Slag Inclusion Fillet (root area)

#39 Tungsten Inclusion SV (root area)

#56 Incomplete Root Penetration SV

#57 Incomplete Root Penetration DV

#59 Incomplete Groove Weld (crown area)

#70 Root Concavity SV

#71 Excess Root Penetration SV

#72 Misalignment Root & Crown SV

#90 Weld Splatter SV

#92 Chipping Hammer Marks SV

Material: Carbon Steel
Kit Spec: 10 Specimens
- (5) Plates @ 0.375”T
- (3) Plates @ 0.625”T
- (1) Tee @ 0.375”T
- (1) Pipe @ 4” Sch80 (0.337” wall)
Flaws: 2 each specimen, 20 total
Doc Pack: Includes C of C, CAD Drawings, Test Sheets & Radiographs
Carrying Case: 2 @ 6” x 16” x 20” each
Weight: ~70LBS
