The PRO TIG 201L AC/DC is the professional TIG welding solution for welding all types of metal up to 4 mm thick (steel, stainless steel, aluminium, copper or titanium). It ensures a very high level of precision in many areas such as fabrication, maintenance or piping. Equipped with a cooling unit, it allows the use of more ergonomic TIG torches. 6 TIG AC/DC processes • Welding current : 10 to 200 A (TIG AC), 10 to 160 A (TIG DC) • TIG DC — Standard : Ensures a quality weld on all ferrous materials such as steel, stainless steel but also copper and its alloys, titanium… • TIG DC Pulse : Controls molten temperature, limits deformation and thus allows the assembly of thin sheets from 0.3 mm. • TIG DC SPOT: Pre-assembles ferrous metal parts by tacking • TIG AC — Easy : Makes the use of the welding machine easier thanks to predefined settings. The user only selects the diameter of his tungsten electrode on the interface. • TIG AC — Standard : Designed for welding aluminium and its alloys (Al, AlSi, AlMg, AlMn…). Alternating current provides cleaning of the aluminium for a perfect weld. • TIG AC — SPOT : Pre-assembles the aluminium parts by tacking. 2 modes of coated electrode welding • Welding current : from 10 to 160 A (MMA) • MMA Standard : Accepts basic, rutile electrodes up to Ø 4 mm. • MMA Pulse : Helps welding in a vertical upright position (nozzles/pipeline). Designed for user comfort • 2 types of start-up : HF (without contact) or LIFT (with contact) for electro-sensitive environments. • 3 trigger modes: — 2 times: maintain pressure on the trigger throughout the weld.
Технические характеристики
CharacteristicsTechniqueMMA, TIG, spotOutput currentDC, ACMaterialfor steel, for stainless steel, for copper, for titanium, for aluminumCurrent
Min.: 10 A
Max.: 200 A
