Description
Head
- Trinocular head, with 70/30 split phototube for attaching of camera
- 30° observation angle
- Focusable eyepieces
- Adjustable interocular distance
- Collapsible rubber eyecups
Objectives
- Plan Semi-Apo flour lens with high N.A. produce flat FOV, and superior resolution and light gathering ability
- Sealed 40X to prevent accidental damage from Use of Oil at 100X
- Infinity corrected
- Anti-reflective optical coatings, for superior optical quality
- Parfocal and parcentered
Stand
- Built-in carrying handle
- Reverse, removable objective turret (6 Position), with DIC slot, allows for easy access to slides
- Adjustable focusing stop protects slides from accidental damage
- Reflected LED transmitted illumination with removable housing
- Rackless X/Y mechanical stage for smooth, fine movement control
- LBD and ND filters built in with pull out levers
- Focusing tension control
- LED brightness control indicator
- Photo preset button for optimized brightness for photography
- Reflected 100 watt transmitted illumination with removable housing
Illumination
- Full Koehler illumination with field diaphragm
- 100w Halogen
Certifications
Quality Proformance Certification
Технические характеристики
| Product Type | Compound Microscope |
| Resolution | Coarse and Fine |
| Warranty | 5 years optical and mechanical, 1 year electrical from date of purchase |
| Electrical Requirements | Internal, 110/220 V Auto Switch |
