Demolition sorting grab IDG4 IDG4 demolition sorting grab has a weight of 330 kg and a mouth opening of 1.250 mm. The maxim hydraulic working pressure is 250-280 bar. TECHNICAL DATA SHEET WEIGHT kg330 MOUTH OPENING mm1.250 HEIGHT mm1.000 JAW WIDTH mm450 BUCKET POSITION ton3 — 5 CAPACITY m30,080 WORKING PRESSURE bar250 — 280 WORKING FLOW l/m50 BLADE FORCE kg2.100 ROTATION PRESSURE bar180 — 200 ROTATION FLOW l/m30
Технические характеристики
CharacteristicsTypesortingOperationhydraulicApplicationsscrapCarrier weight
2,100 kg (4,630 lb)
