last updated : 2022/02/28
| Code | Description | Budget Price | Ship. weight | Ship. vol. | ||
|---|---|---|---|---|---|---|
| EELELAPOFAM1 | LAMP, SOLAR led for familly — Li-ion battery | on request | 0,151kg | 0 | Add | |
| Dangerous : DGR-UN 3481 | ||||||
General information
Weather proof and shockproof solar lamp. This lamp is meant for distribution as an Essential Household Item, for family usage.
Time to charge: 12 hours sun light.
Rechargeable lithium-ion batteries only.
Lithium-ion requires declaration for transport of dangerous goods, under UN3481.
Lifespan: 2 years minimum in daily use.
Shelf life: 5 years when kept in original packaging between –10°C and 50°C. The lights are delivered with partially charged batteries, it is recommended to re-charge the batteries before use to insure full maximum power. When stored fully charged, the batteries will hold charge for approximately 1 year, slowly discharging.
Specifications
Lamp, solar: | Rechargeable by solar panel and 220 V (cable and charger must be provided with the lamp, charger can be integrated or separate) |
General quality: | Up to the highest industry standards. |
Connectors | Female USB outlet, to charge a mobile phone. Female Micro-USB inlet for connecting the solar panel or the charger |
Features: | 2 positions only, high beam and low beam. Battery charging indicator light |
Material: | Casing made of shockproof plastic |
Waterproof: | Rain resistant |
Charge cycles: | Low Self Discharge, 500+ charges |
Battery protection: | Automatic protection against deep battery discharge and overcharge |
Light output angle: | 360 degrees, omnidirectional |
Total Lux: | See table below |
Solar panel: | Integrated or separate (with a 3m cord with male Micro-USB connector to connect to the Micro-USB inlet of the lamp or to charge a mobile phone). |
Time to fully charge: | 12h maximum bright sun light |
Charging outlet (USB-A) performances: | Outlet minimum voltage with no load: 5V |
Outlet minimum current with load: 0.4A at 4.5V | |
Outlet minimum available energy: 3.5Wh | |
Outlet minimum available energy after 4 hours charge starting from 100% discharged battery: 1Wh | |
Fixation system: | Foldable handle, hook, strap or other mechanism to suspend the lamp e.g. from tent pole or branch. |
Packaging: | Wrapped in soft cardboard for protection (no |
plastic bags), packed in an individual strong cardboard box. | |
IATA packaging compliant with lithium-ion batteries regulation. | |
Marking: | recommendation to recycle batteries |
Brightness test | ||
High brightness (duration test: 3 hours). Charging time: 12 hours. Unit: Lux | ||
Minimum average brightness at full light at beginning: | 28 | |
Minimum average brightness at full light after 2h: | 17 | |
Minimum average brightness at full light after 3h: | 9 | |
Low brightness (duration test: 6 hours). Charging time: 12 hours. Unit: Lux | ||
Minimum average brightness at low light after 4h: | 5 | |
Minimum average brightness at low light after 6h: | 2 | |
Measuring conditions:
For both low and high brightness, the sensor is placed at 1m distance from the lamp, on the same surface where the lamp is standing.
Documents Quality control.pdf Sustainable procurement.pdf
